The Wemos D1 Mini is a mini WiFi board based on the ESP-8266EX. It offers a perfect balance between size and functionality. Despite its tiny size (approx. 34mm x 25mm), it packs a full WiFi stack, 4MB of flash memory, and 11 digital input/output pins. It is widely loved by the “Home Assistant” and “ESPHome” communities because it can be hidden inside light switches, small sensors, or 3D-printed enclosures where a standard NodeMCU simply won’t fit.
Key Features
Ultra-Compact Footprint: Less than half the size of a NodeMCU, making it ideal for wearable and space-critical IoT.
Plug-and-Play USB: Features a Micro-USB port for easy programming and power (using the CH340 or CP2104 driver).
Arduino Compatible: Program it using the Arduino IDE, MicroPython, or Lua.
WiFi Connectivity: Integrated 802.11 b/g/n support for cloud data logging and remote control.
Shield Ecosystem: Compatible with a wide range of “D1 Mini Shields” (Relay, DHT11, MicroSD, etc.) that stack directly on top.
Technical Specifications
Feature
Specification
Microcontroller
ESP-8266EX (ESP-12E Module)
Operating Voltage
3.3V (Onboard 5V to 3.3V Regulator)
Digital I/O Pins
11 (All support Interrupt/PWM/I2C/One-Wire)
Analog Input
1 (Max input: 3.2V)
Clock Speed
80 MHz / 160 MHz
Flash Memory
4 Megabytes
USB Interface
Micro-USB (Power and Data)
Dimensions
34.2mm x 25.6mm
