Inverter Drive Modules in Pakistan
Explore inverter drive modules in Pakistan for solar inverters, UPS systems, hybrid inverters, grid-sharing applications and DIY power-electronics projects. These dedicated inverter control boards provide SPWM control and are designed to work with external MOSFET or IGBT power stages.

Our range includes popular STM Sinewave Inverter Drive Modules such as IDM-2, IDM-3, IDM-4, IDM-5, IDM-6 and IDM-7. Different IDM versions are available with different display, CT sensing and inverter-control configurations.
Popular IDM Inverter Modules
IDM-7 is an STM sinewave inverter drive module designed for grid-sharing and hybrid inverter applications. It can be paired with a CT sensor and display interface for inverter monitoring and control.

IDM-6 provides STM-based sinewave inverter control with CT input and display connectivity, making it suitable for inverter and power-electronics projects.

IDM-5 is an STM sinewave inverter drive module with grid-sharing capability and CT input for inverter control applications.

IDM-4 combines STM sinewave inverter control with a 3.5-inch TFT display and cable connection for a more advanced monitoring interface.

IDM-3 is an STM sinewave inverter drive module designed with a 3.5-inch TFT display interface.

IDM-2 is designed as a pin-to-pin replacement-style inverter control solution for compatible dsPIC30F2010-based inverter designs.
Applications
These inverter drive modules are commonly used in:

Solar inverter projects
Hybrid inverter systems
UPS systems
Grid-sharing inverters
Pure sine wave inverter projects
Battery backup systems
MOSFET inverter power stages
IGBT inverter power stages
DIY solar power systems
Power electronics development
Inverter repair and replacement projects

Depending on the model, features can include SPWM generation, selectable carrier frequency, CT current sensing, LCD/TFT display support, serial communication, protection functions and configurable inverter operating modes. For example, IDM-7 documentation and listings specify 5V DC operation, selectable 6/12/18 kHz carrier frequency, 50 Hz output frequency and support for 16×2, 20×4, HT1621 and i-Mux TFT display options.

When selecting an IDM module, check the model number, battery voltage configuration, display compatibility, CT requirements, PWM output requirements and compatibility with your MOSFET/IGBT power stage.

Shop inverter drive modules in Pakistan, including IDM-2, IDM-3, IDM-4, IDM-5, IDM-6 and IDM-7, for solar inverter, UPS, hybrid inverter and power-electronics applications.
