2MBI100N-060 600V 100A IGBT Module – Fuji Electric Power Switching Module for Inverter Repair

Overview

The 2MBI100N-060 is a high-speed switching IGBT (Insulated Gate Bipolar Transistor) module designed for high-power applications. If you are a technician repairing a local inverter or an industrial VFD (Variable Frequency Drive), this is likely the exact part you need. It features a “2-in-1” package design, making it efficient for half-bridge configurations in power inverters and servo drives.

Key Features

• Industrial Durability: Features a square Reverse Biased Safe Operating Area (RBSOA), ensuring the module can handle high-stress switching cycles without failing.

• Low Power Dissipation: With a low saturation voltage ($V_{CE(sat)}$), it runs cooler than generic alternatives, increasing the lifespan of your repair.

• High-Speed Performance: Fast turn-on and turn-off times minimize switching losses, crucial for high-frequency inverters.

• Compact & Rugged: Standardized footprint for easy replacement in existing inverter chassis.

• Isolation Protection: 2500V isolation voltage keeps the control circuitry safe from the high-power DC bus.

Technical Specifications

Ideal Applications

• Local Solar Inverter Repair: The primary choice for 5kVA+ inverter power stages.

• Motor Control: Variable Frequency Drives (VFDs) and AC/DC Servo drives.

• Welding Machines: Power stage for high-current welding converters.

• UPS Systems: Industrial-grade Uninterruptible Power Supplies.
