Overview
The ESP32-CAM is a small-form-factor camera module that can operate independently as a least-cost system. It features the powerful ESP32 dual-core processor, a 2-Megapixel OV2640 camera, and an onboard MicroSD card slot for local image storage. It also includes a high-brightness Flash LED, making it capable of capturing photos and video even in low-light conditions. It is fully compatible with the Arduino IDE and ESP-IDF, making it a favorite for “Smart Home” developers across Pakistan.
Key Features
Powerful Imaging: Includes the OV2640 camera module (supports JPEG, BMP, and Grayscale).
Wireless Freedom: Built-in WiFi 802.11b/g/n and Bluetooth 4.2 (Dual Mode).
Storage Ready: Integrated MicroSD card slot (supports up to 4GB) for data logging or saving snapshots.
Built-in Flash: Includes a bright “Flash” LED to illuminate dark environments.
PSRAM Boost: Comes with 4MB of external PSRAM to handle high-resolution image buffering smoothly.
Technical Specifications
| Feature | Specification |
| Microcontroller | ESP32-S Dual-core 32-bit LX6 |
| Camera Sensor | OV2640 (2 Megapixels) |
| Flash Memory | 32Mbit (Internal) |
| PSRAM | 4MB (External) |
| Clock Speed | Up to 240 MHz |
| Interface | UART, SPI, I2C, PWM, ADC, DAC |
| Flash LED | Integrated 3030 LED |
| Operating Voltage | 5V DC (Recommended) |
