MT3608 DC-DC Step-Up Boost Converter Module 2A – Adjustable Voltage Regulator 2V-24V to 5V-28V

The MT3608 is a compact and highly efficient power module designed to increase low input voltages to a higher, stable output level. It is widely used in robotics and portable electronics to boost power from 3.7V lithium batteries or USB ports to higher voltages required by motors, Arduinos, and sensors.

This module features a high switching frequency of 1.2MHz, allowing it to maintain a small footprint while delivering up to 93% efficiency. It includes built-in thermal overload protection and a multi-turn potentiometer for precise output voltage control.

Technical Specifications:

• Input Voltage: 2V to 24V

• Output Voltage: 5V to 28V (Adjustable)

• Maximum Output Current: 2A (1A recommended for continuous use)

• Efficiency: Up to 93%

• Switching Frequency: 1.2 MHz

• Operating Temperature: -45°C to +85°C

• Dimensions: 36mm x 17mm x 7mm

• Weight: 4g
