SG90 Micro Servo Motor 9g – 180 Degree Rotation for Arduino, Robotics & RC Planes

The SG90 Micro Servo is the most popular choice for hobbyists and students building lightweight robotics and RC projects in Pakistan. Weighing only 9 grams, this tiny but powerful motor provides precise 180-degree rotation (90 degrees in each direction).

It is designed to work seamlessly with Arduino, Raspberry Pi, and most standard radio control systems. The package includes three different functional horns (arms) and mounting screws, making it ready for immediate use in robotic arms, steering systems for RC cars, or flight control surfaces for model airplanes. Its high-quality plastic gears and fast response time ensure reliable performance for your DIY automation needs.

Technical Specifications: * Model: SG90 TowerPro (Original Core)

• Weight: 9 grams (Motor only)

• Operating Voltage: 4.8V to 6.0V

• Stall Torque: 1.8 kg-cm (at 4.8V)

• Operating Speed: 0.12 seconds / 60 degrees (at 4.8V)

• Rotation Range: 180 Degrees

• Gear Type: Nylon / Plastic

• Connector Wire Length: 250mm

• Pinout: Brown (Ground), Red (Positive), Orange (PWM Signal)

• Dimensions: 22.2mm x 11.8mm x 31mm
