Overview
The SOP16 to DIP16 Adapter Board is a high-quality FR4 glass fiber PCB designed to make your life easier during the prototyping phase. If you have an SMD chip (like a shift register, motor driver, or logic gate) that only comes in an SOP/SOIC package, this board allows you to solder the chip onto the top and add standard header pins to the bottom. Once assembled, your SMD chip behaves just like a traditional DIP chip, fitting perfectly into breadboards, Vero boards, or 16-pin IC sockets.
Key Features
Double-Sided Versatility: Usually features two different footprints (SOP16 on one side, SSOP16 on the other) to accommodate various chip widths.
Standard 2.54mm Pitch: Converts the narrow 1.27mm SMD pin spacing to the standard 0.1″ (2.54mm) spacing used in the hobbyist world.
High-Quality Finish: Features tinned pads for easy soldering and a durable green solder mask to prevent bridges.
Compact Footprint: Minimalist design ensures it doesn’t take up unnecessary space on your breadboard.
Technical Specifications
| Feature | Specification |
| Supported Packages | SOP16, SOIC16, SSOP16, TSSOP16 |
| Pitch (SMD Side) | 1.27mm / 0.65mm (Depending on side) |
| Pitch (DIP Side) | 2.54mm (Standard Breadboard) |
| Material | FR-4 Glass Fiber PCB |
| Board Thickness | 1.6mm |
| Dimensions | Approx. 21mm x 15mm |
